Jacketed heated storage tanks

①This series of containers are manufactured, pressure tested and accepted in accordance with the "Technical Conditions for Steel Welded Containers".

②The storage tanks are available in various models from 100L to 10000L for your selection, and can also be designed and processed according to the actual needs of customers.

③The storage tank interface adopts the universal ISO standard quick-release chuck type.

④The inner material of the storage tank is imported 316L or 304.

⑤The storage tank is equipped with a liquid level gauge, thermometer, tank washing ball, air respirator, sterilization steam port, manhole, liquid inlet and outlet and circulation system interface.

◆Internal shape: vertical barrel (inner cylinder in contact with liquid medicine)

◆Internal material: 316L (imported)

◆Internal finish: 0.28-0.45μm

◆Exterior material: 304 mirror plate or matte plate

◆Insulation material: pearl cotton (high temperature resistant, anti-aging)

◆Exterior temperature: ≤20℃

◆Sterilization pressure: 0.15-0.3Mpa or normal pressure

◆Sterilization temperature: 121℃-132℃

◆Working pressure: normal pressure

◆Working temperature: 80℃-95℃

◆Thermometer

◆Liquid level gauge

◆Respirator, tank washing ball

◆Manhole

◆Breathing port

◆Steam port and condensate port

◆Inlet and outlet and circulation system interface
